22
7 Set up with the integrated display and adjustment unit
VEGAMET 841 • 4 … 20 mA
58864-EN-200401
7.3 Menu overview
Description Basic settings
Damping Time setting for damping
Linearisation Linearization settings
Adjustment Adjustment settings
Scaling Scaling settings
Outputs Relay/current output settings
Description Basic settings
Number of measured
value windows
Number of displayed measured value windows
Measured value window Measured value window settings
Options Display options e.g. brightness, contrast, illumina-
tion
Menu language Language settings
Description Basic settings
Fail safe relay Activate/deactivate fail safe relay
Access protection Access protection for Bluetooth and protection of
the parameter adjustment
Reset Reset of the device
Description Basic settings
Status Status indication, e.g. device, sensor, relay
Simulation Simulation function
Device-TAG Display device name
Device information Device information, e.g. serial number
7.4 Setup steps
Through parameter adjustment, the instrument is adapted to the indi-
vidual application conditions. A measurement loop calibration is the
most important step and should always be carried out. A scaling of
the measured value to the desired physical variable and unit, possibly
including a linearisation curve, is often useful. The adaptation of the
relay switching points or the setting of an integration time to smooth
the measured value are further standard adjustment options.
Information:
When using PACTware and the respective DTM or the VEGA Tools
app, additional settings can be carried out which are not possible or
only partly possible with the integrated display and adjustment unit.
Communication takes place via the built-in Bluetooth interface.
Measurement loop
Indication
Extended functions
Diagnostics
Parameter adjustment
