14 Supplement
VEGAMET 841 • 4 … 20 mA
58864-EN-200401
Protection against dangerous body currents
Reliable separation according to IEC/EN 61140 by reinforced insulation according to IEC/
EN61010part1upto253VAC/DCwithovervoltagecategoryIIandfullledenclosureprotection
class between the supply, signal and relay circuits.
Sensor inputs (active) are energy limited circuits according to IEC/UL 61010 part 1.
14.2 Overview applications/functionality
The following charts provide an overview of the standard applications and functions of VEGAMET
800 series controllers. They give also information about whether the respective function can be
activated and adjusted via the integrated indicating and adjustment unit (OP) or via DTM/app.
5)
Applications (adjustable with DTM/app) VEGAMET Adjustment
841 842 861 862 OP DTM/
App
Universal • • • • • •
Level storage tank • • • • •
Calculationdierence • • •
Flowmeasurementume/weir • • • • •
Pumping station • • • • •
Screen control • • •
Sewage screw lifting station • • • • •
Additional application examples VEGAMET Adjustment
841 842 861 862 OP DTM/
App
Level measurement • • • • •
Gauge measurement • • • • •
Process pressure measurement • • • • •
Functions VEGAMET Adjustment
841 842 861 862 OP DTM/
App
Application wizard • • • • •
Indication measured values • • • • • •
Automatic display change • • • • • •
Display multilingual • • • • • •
Sensor input 4 … 20 mA • • • • • •
Sensor input HART • • • •
Damping • • • • • •
Linearization preset curves • • • • • •
Linearization dimensions ISO standard • • • • •
5)
OP: Operating Panel (integrated display and adjustment unit)
