60
11 Supplement
VEGADIS 82 • 4 … 20 mA/HART
45300-EN-240516
11 Supplement
11.1 Technical data
Materials and weights
Materials
Ʋ Plastic housing Plastic PBT (Polyester)
Ʋ Aluminium housing Aluminium die-casting AlSi10Mg, powder-coated (Basis:
Polyester)
Ʋ Stainless steel housing 316L precision casting
Ʋ Seal between housing and housing lid NBR (stainless steel housing), silicone (Aluminium/plas-
tic housing)
Ʋ Inspection window in housing cover
(in version with display and adjust-
ment module)
Polycarbonate, coated
Ʋ Cable gland/Seal insert PA/NBR
Ʋ Ground terminal 316L
Deviating materials - Ex d version
Ʋ Inspection window in housing cover
(in version with display and adjust-
ment module)
Single-pane safety glass
Ʋ Cable gland/Seal insert Brass nickel-plated/NBR
Materials for carrier rail mounting
Ʋ Adapter plate, housing side 316
Ʋ Adapter plate, carrier rail side Zinc die casting
Ʋ Mounting screws 316
Materials for tube mounting
Ʋ Brackets StSt
Ʋ Mounting screws StSt
Materials for panel mounting
Ʋ Housing PPE
Ʋ Transparent cover PS
Ʋ Screw clamps St, nickel plated
Material sun protection 316L
Weights without mounting elements approx.
Ʋ Plastic housing 0.35 kg (0.772 lbs)
Ʋ Aluminium housing 0.7 kg (1.543 lbs)
Ʋ Stainless steel housing 2.0 kg (4.409 lbs)
Mounting elements approx.
Ʋ Brackets for tube mounting 0.4 kg (0.882 lbs)
Ʋ Adapter plate for carrier rail mounting 0.5 kg (1.102 lbs)
