Volkswagen Elli Charger User Manual

Elli Charger 15
EN
Prepare for installation
4. Prepare for installation
4.1. Content of delivery
Position Description Quantity
1 Bezel 1
2 Front cover 1
3
Main assembly
A. Elli Charger Pro with kWh meter
B. Elli Charger or Elli Charger Connect with feed-through
terminals
1
4 Wall bracket 1
5 Charging cable 1
6 HMI cable 1
7 RFID cable * 1
8 RS485 cable ** 1
9 Fastening kit for main assembly 1
10 Fastening screws for front cover 1
11 Installation and User Manual A 1
12 Installation Manual B 1
* For Elli Charger Connect and Elli Charger Pro only. ** For Elli Charger Pro only.
Your Elli Charger Pro comes equipped with a kWh meter, and it is compatible
with different types of kWh meters. For example, a 3-phase kWh meter will
also be compatible in a 1-phase wallbox, as shown in the following table.
