Elli Charger 25
EN
Install wallbox
5.3. Mount main assembly onto wall bracket
B 5.3
See the corresponding illustrations in manual B.
1. Engage the top edge of the main assembly with the top of the wall bracket
and then rotate the main assembly so it is flat on the wall bracket.
2. Mount main assembly.
WARNING
Not mounting all the screws and washers on the inside of the main assembly when
mounting it onto the wall bracket will affect the protection against moisture of the wallbox,
which can result in the risk of electric shock.
— Make sure that all screws together with their corresponding washers are mounted.
While holding the main assembly in place, insert the four screws M6 x 16 mm
together with the bonded sealing washers 6.6 mm x 11 mm and fasten them.
5.4. Assemble wallbox
B 5.4
See the corresponding illustrations in manual B.
1. Install power supply cable.
CAUTION
Using stranded wires without ferrules may result in improper installation, which can cause
accelerated aging of electric components and/or loss of electric connection.
— Use crimped insulated ferrules for 1-phase installation.
— Use crimped uninsulated ferrules for 3-phase installation.
a. Strip the outer insulation of the cable to a length of 50 mm,
then strip the individual wires to 12 mm.
b. Route the cables to their connection terminals.
Ensure that the bending radius is within the limits for the cable type.
c. Connect the wires according to the Elli Charger model
and the color coding table below.
