4
2
-7
Protruding segment of bonded rubber mounting faces
forward on inside and rearward on outside.
Fig. 7
Rubber bo
n
ded mountin
g
, installation
position
Press both halves in one after the other until the
mounting conical section contacts the axle beam.
Fig. 8
Rubber bo
n
ded mountin
g
, presssi
n
g
into axle beam
Page
7
of
14
Rear Wheel Suspension, Shafts and Axle
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&ty
p
e=repair&id=VW.B4.SU01.42.1
102
