4
6
-16
6
-
Outer wheel bearing
7
-
Wheel s
p
eed sensor
r
o
tor
Only on vehicles with
ABS
8
-
Brake drum
Vehicles with front
wheel drive
Brake drum diameter:
230 mm
Wear limit: 231.5 mm
Clean thoroughly,
check for wear,
damage, tolerances,
damaged wheel bolt
threads and condition
of braking surface
Fill hub with multi-
purpose grease
Check for ovality
9
-
Stub axle
Page
2
of
4
Rear wheel brakes, servicing (drum brakes)
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&ty
p
e=repair&id=VW.B4.SU01.46.3
211
213
