48-9
Installing
- Install steering wheel, install nut and tighten.
Tightening torque: 50 Nm (37 ft lb).
- Connect airbag unit connector below steering
wheel.
- Install trim panel below steering column. Make
sure that the centering ring wiring connection is
located in the recess in the trim panel.
- Connect connector in steering wheel to airbag
unit connector.
- Install airbag unit Page 48-7
Note:
Use new hex socket head bolts for airbag unit.
- After installing the airbag steering wheel first
switch on ignition, then connect battery Ground
strap.
CAUTION!
Make sure that no one is in the vehicle when
connecting the battery Ground strap.
