48-53
Needle run-out max. 0.10 mm
If needle run-out is greater than 0.10 mm, screw
pressure piece slightly into housing
If the needle run-out is less than 0.10 mm, screw
pressure piece slightly out of housing
- Tighten lock nut
- Check needle run-out again, if necessary repeat
adjustment
- Remove gauge
Close hole in adjusting screw with a stopper from
repair kit
Tie rods, installing
- First install clip -2- with gasket -1- in the hole
- Apply 1 drop sealing compound, Part No. AMV
188 001 02, in the hole of the clip -arrow- and
press plug -3- into the clip
-
See tie rods, removing and installing (TRW and ZF
steering gear), Page 48-77
