Parts, cleaning a
n
d checking
-
Before assembly, the housing must be checked for
contamination (paint residue, chips, dirt) and clean
thoroughly with compressed air and alcohol if
necessar
y
-
Check cylinder race for scoring or other damage. If
scoring can be felt, replace the complete steering
gear
-
Clean toothed rod (remove old grease in tooth
pockets)
Page
68
of
99
Steering
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&ty
p
e=repair&id=VW.B4.SU01.48.1
337
339
