48-76
- Carefully slide bushing with roller bearing onto the
valve body.
- Drive bushing into the housing far enough so that
the groove for the circlip is visible.
- Install circlip.
- Remove adhesive tape.
- Remove installation mandrel 3315/17.
-
Install Torx screw into valve body and tighten to 35
Nm (26 ft lb).
- Thread in locking screw, tighten to 30 Nm (22 ft lb)
and crimp at corner points.
- Grease pressure piece with AOF 063 000 04.
- Install pressure piece, spring and washer in
housing.
- Install cover with adjusting screw. Adjust steering
gear after installation in vehicle.
Page
76
of
99
Steering
12/7/2004
