6 Components and operating elements
18 100_0201_cp_0005.fm
6 Components and operating elements
Item Designation Item Designation
1 Central suspension 9 Air filter system
2 Guidance clip 10 Exhaust
3 Fuel cock 11 Oil sight glass
4
Fuel tank
12 Handle
5 Gas regulating lever 13 Rammer base
6 Reversing starter 14 Rammer system
7 Drive motor 15 Bellows
8 Vibration damper 16 Maker's plate
