13 Technical data
34 100_0201_td_0005.fm
13 Technical data
13.1 Noise and vibration information
The noise and vibration information listed was determined in accordance with the following directives for
typical machine operating conditions/special trial conditions and applying harmonized standards:
 Machinery Directive 2006/42/EC
 Noise Emission Directive 2000/14/EC
In operation, values differing from these may arise, depending on the operating conditions prevailing.
13.1.1 Noise information
Sound pressure level at the place of use
 LpA was determined in accordance with EN ISO 11201 and EN 500-4.
Guaranteed sound output level
 LWA was determined in accordance with EN ISO 3744 and EN 500-4.
13.1.2 Hand-Arm-Vibration (HAV) information
Weighted total vibration
 HAV was determined in accordance with EN ISO 20643 and EN 500-4.
13.2 DS70
Designation Unit DS70Y 13"
Part no. 5100030612
Impact rate per
minute
667
Impact force kN 21
Advance m/min
8,8
Length mm 740
Width mm 370
Height mm 1,000
Length (rammer shoe) mm 340
Width (rammer shoe) mm 330
Weight kg 83
Operating output kW 3.1
Operating speed* rpm 3,450
Standard ISO 3046-1
Operating temperature range °C -10 – +40
Sound pressure level L
pA
dB(A)
94
Sound output level L
WA
measured
guaranteed
dB(A)
dB(A)
107
108
Total vibration value a
hv
m/s
2
11.9
Measuring uncertainty of the
total vibration value a
hv
m/s
2
1.5
Oil specification SAE 10W-40
Oil volume l
0.8
*
Dependent on operating parameters, material properties and environmental factors.
