20
Description EHB 11
5.3 Components and operator's controls
Tool holder
The machine is available with three different tool holders:
SDS-max
Hexagonal with locking strap
Spline shaft
ON/OFF switch
A start-up protection is linked with the ON/OFF switch. This start-up protection
has the effect that the percussion rate or speed of the rotary hammer rises slowly
after pressing the ON/OFF switch. The start-up protection prevents or reduces
the chisel from slipping or the drill from jamming.
Item Designation
1 Tool holder
2 ON/OFF switch
3 Thumbwheel for pre-selecting
speed
4 Adjusting lever for chiseling/
hammer drilling
5 Supplementary handle
6 Adjustable depth gauge
