Operation EHB 11

7.3.4 Tool holder for tool with spline shaft

Inserting tool

1. Clean tool end.

2. Turn lock bolt by 90°.

3. Push tool into the tool holder as far as it will go.

When inserting a chisel, make sure the notch on the tool points towards the

spline shaft.

4. Turn lock bolt back by 90°.

5. Check to see if the tool is locked by pulling on the tool.

Removing tool

1. Turn lock bolt by 90°.

2. Remove tool from the tool holder.

3. Return lock bolt to original position.

Item Designation

1Tool

2 Lock bolt
