EHB 11 Technical data
43
12 Technical data
12.1 EHB 11 BL/BLM - 230
Designation Unit EHB 11 BL EHB 11 BLM
Item no. 0008395
0008919
0008740
0008754
0610233
0008731
0008920
0008743
0008997
0610234
Length x Width x Height mm (in) 560 x 105 x 245
(22.0 x 4.1 x 9.7)
620 x 105 x 245
(24.4 x 4.1 x 9.7)
Weight kg (lb) 11 (24.3) 11.7 (25.8)
Rated voltage V 220-240 1~
Rated frequency Hz 50-60
Rated power consumption kW 1.38
Rated current consumption A 7.5
Minimum generator output re-
quirement for single connection
kW 3.3
Percussion rate electronically
adjustable
rpm 1,300-2,150
Drill speed electronically adjust-
able
rpm 140-220
Single stroke energy J 19
Breaking output (concrete C25) kg/h (lbs./h) 600 (1,323)
Tool holder hex 19 x 82.5 SDS-max
Special lubricating grease Shell Retinax LX2
Drive Three-phase AC motor
Class rating *
* According to DIN EN 61140, description see 12.4 Notes regarding class rating
(page 46).
II
Sound pressure level L
PA
at op-
erator's station **
** According to ISO 11201.
dB(A) 93 94
Total vibration value of the ac-
celeration a
hv
***
*** Determined according to DIN EN ISO 5349.
m/s
2
9.8
