EHB 11 Technical data
47
12.5 Extension cable
A permitted extension cable must fulfill the following criteria:
The extension cable must be undamaged.
The extension cable has to be connected correctly on plug and bushing.
The extension cable has to be suitable for use at construction sites: Average
rubber hose H05RN-F or better – WACKER recommends H07RN-F or a
country-specific equivalent design.
The extension cable must have been checked by a qualified electrician.
The required cross-section area of a designated extension has been taken
from the table below.
Note: Refer to the nameplate or the chapter Technical data (via the item
number) for the type designation and voltage rating of your machine.
Voltage
[V]
Extension
[m]
Cross-section
area of cable
[mm
2
]
110–130 < 8 1.5
< 13 2.5
< 20 4.0
< 30 6.0
220–240 < 27 1.5
< 44 2.5
< 70 4.0
< 105 6.0
