EHB 11 Technical data
45
12.3 EHB 11 BLS - 115
Designation Unit EHB 11 BLS
Item no. 0008742
Length x Width x Height mm (in) 620 x 105 x 245
(24.4 x 4.1 x 9.7)
Weight kg (lb) 11.5 (25.4)
Rated voltage V 110-127 1~
Rated frequency Hz 50-60
Rated power consumption kW 1.2
Rated current consumption A 13
Minimum generator output re-
quirement for single connection
kW 3.3
Percussion rate electronically
adjustable
rpm 1,300-2,150
Drill speed electronically adjust-
able
rpm 140-220
Single stroke energy J 19
Breaking output (concrete C25) kg/h (lbs./h) 600 (1,323)
Tool holder Large spline shaft size 19
Special lubricating grease Shell Retinax LX2
Drive Three-phase AC motor
Class rating *
* According to DIN EN 61140, description see 12.4 Notes regarding class rating
(page 46).
II
Sound pressure level L
PA
at op-
erator's station **
** According to ISO 11201.
dB(A) 93
Total vibration value of the accel-
eration a
hv
***
*** Determined according to DIN EN ISO 5349.
m/s
2
9.8
