EPG-SPRINT.
OPERATING MANUAL
VERSION 08/2010
ORDER NUMBER DOC 2305222
Quantity Order No. Designation
1 2305109 EPG-SPRINT (for manual and automatic systems)
1 2305127 EPG-SPRINT FM (for USA)
The standard equipment includes:
1 2305227 Declaration of conformity
1 2305220 Operating manual German
1 see chapter 1.1 Operating manual in the local language
4.2 DELIVERY SCOPE
Dimensions:
Height 136 mm; 5.35 inches
Width 270 mm; 10.63 inches
Depth (without operating elements) 200 mm; 7.87 inches
Weight 3.3 kg; 7.28 lb
Electrical:
Mains (AC) 85 VAC-250 VAC
Frequency 47 Hz-440 Hz
Input power max. 40 W
Output voltage max. 22 Vpp
Output current max. 0.9 A
High-voltage 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 µA-120 µA (adjustable in 1 µA steps)
Tribo current measurement 0 µA-5 µA (resolution 0.5 µA)
Tribo current low level warning 0 µA-5 µA (adjustable in 0.1 µA steps)
Tribo current cut off higher than 12 µA
(ATEX: switch the unit off)
Protection class IP 64
Explosion zone II 3(2)D 80°C; 176°F
