6.5.7 DISPLAYING ACTUAL VALUE OF CURRENT LIMITING
Procedure:
1. Press “current limitation“ button 29
for around 2 seconds. Yellow LED 30
fl ashes quickly.
The actual current limitation value
is shown in the LED display 19 for
5 seconds, the display returns to
the previous display after this time.
The actual value display can be inter-
rupted also before expiration of the
5 seconds by pressing a selection
button or turning rotary controller.
The actual current limitation value can be displayed in LED display 19 during the coating
process.
19
24
29
30
