WAGNER HC 960 User Manual

HC920•HC940•HC960 37
GB
Description of unit
3.7 Technical data for gasolline HC units
HC 920 HC 940 HC 940-SSP HC 960 HC 960-SSP
Gasoline engine, power
3 kW: R
4.1 kW: R R
6 kW: R R
Max. operating pressure
22.8 MPa (228 bar): R R R R R
Max. volume ow
5.5 l/min: R
8 l/min: R R
12 l/min: R R
Volume ow at 12 MPa (120) bar
5 l/min: R
7.6 l/min: R R
11 l/min: R R
Max. size of tip with a spray gun
0.043 inch – 1.10 mm: R
0.052 inch – 1.30 mm: R R
0.056 inch – 1.42 mm: R R
Max. temperature of the coating material
43° C: R R R R R
Max. Viscosity
40.000 mPa·s: R
50.000 mPa·s: R R
65.000 mPa·s: R R
Filter insert (standard equipment)
5 Maschen: R
0 Maschen: R R R R
Weight
74 kg R
76 kg R R
88 kg R R
Hydraulic oil lling quantity
4.7 l ESSO Nuto H 32: R R R R R
max. Reifendruck
0.2 MPa (2 bar): R R R R R
Special high-pressure hose
DN 10 mm, 15 m, connection thread NPSM 3/8: R R
DN 13 mm, 15 m, connection thread NPSM 1/2: R R R
DN 19 mm, 15 m, connection thread NPSM 3/4: R R R
Hose whip
DN 10 mm, 2.5 m, connection thread NPSM 3/8: R R R
Dimensions L x W x H
1160 x 955 x 655 mm: R
1185 x 955 x 655 mm: R R
1200 x 955 x 655 mm: R R
Max.sound pressure level:
90 dB (A)* R
92 dB (A)* R R
98 dB (A)* R R
*Placeofmeasurement:1mdistancefromunitand1.60mabovereverberantoor,120bar(12MPa)operatingpressure.
