Selecting the proper tip
Your sprayer comes with a variety of spray tips depending on the model:
a wide angle tip, a round tip, and a stain tip (optional).
Wide angle tip
The wide angle tip produces a wide pattern that can be adjusted horizontally or
vertically.
To adjust:
1. Make sure the sprayer is unplugged.
2. Loosen the wide angle tip by turning the tip counterclockwise 1/4 turn.
3. Turn the adjusting arm so that it is pointing down for a horizontal pattern. Turn the
adjusting arm so that it is pointing to the side for a vertical pattern.
4. Tighten the tip firmly by hand.
Use the wide angle tip for covering a large, flat surface. It works well with most water-
based paints and stains. The wide angle tip is not recommended for use with oil-
based paints.
