Using the suction extension
The suction extension includes a hose set, dual hose fitting, pump housing
locking collar, suction set hose adapter, and a container clip.
It allows you to attach the sprayer to a larger container such as 4 or 20 litres
paint can or an optional backpack.
1. Place a few drops of household oil down the intake (center) and return (back)
openings in the pump housing.
2. Push the dual hose fitting into the intake and return openings on the bottom of
the housing. The fitting with the ridge goes into the return opening.
3. Place the pump housing locking collar over the dual hose fitting and turn the
locking collar clockwise until it locks securely.
4. Push the suction hose set onto the intake and return ports of the dual hose
fitting. The hose with the writing on it goes to the intake (center) port.
