Connections of the device
Things to note about the connections
In installation, to make the mounting and demounting for service easier, it is recom-
mendedtoleavesomeextralengthofloosecablesandfuellinebycreatingacoil.
If the installation location is cramped, it is recommend to connect the cabels and
the fuel line to the device before mounting the unit to bracket. This will help the
installation of device.
Power cable
Install the combustion gas ex-
hausthosetothishosetting
Control panel
Install the combustion air in-
takehosetothishosetting
