wallas xs duo User Manual

5 l 2024
10 l
30 l
130 l
2027
4030
4130
200x300x130mm
380x195x210mm
590x200x300mm
800x400x600mm
en
Installation
Fuel connections
Things to note about the connections
Thestandardlengthofthefuelhoseis4m(max8m).Cutthefuelhosetoalength
suitable for installation.
The lift height of the pump should be less than 2 m; preferably 0.5 – 1 m.
ThefuelpipemustalwayshaveaWallaslter.Thefuelltercanbeinstalled
either near the device, near the tank, or in another location where it can be easily
checked and replaced, when necessary.
Dieselenginefuelltersand/orseparatorsarenotapprovedforuse.Allsoftcon-
nections should be made with rubber or silicone hose which is resistant to diesel.
Country-specicrequirements
Thestandardfuelhoseisplastic.Pleaseobservecountry-specicrequirements
withregardtothematerialofthefuelhose/pipeandthefuellter.Theinnerdiam-
eterofanewreplacementhoseshouldbeequaltotheinnerdiameteroftheplastic
hose. Copper pipe 300692andmetallters30016 are available as accessories.
Fuel feed
Iftheliftheightexceeds2m,thefuelfeedmustbecheckedand,ifnecessary,ad-
justed. The fuel feed must also always be checked, if parts of the fuel system, such
as the pump or the electronics card, have been replaced.
Fuelsystemadjustmentsaredevicespecic.Theseadjustmentsshouldonlybe
carried out by an authorized service shop.
Connectiontoaxedtank
Thedevicemusthaveadedicatedconnectionwithafuellteroutsidethetank.
Please note that installation of such fuel intake pipe to the original tank of the
vehiclemayaltertheoriginalcerticationofthevehicle.Certiedinstallationmay
requireaseparateapprovalofthefuelintakeconnection.Ifthevehiclehasalready
a tube end where you can connect the fuel tube of XC Duo, you do not need any
separate approval.
Connection to a separate tank
Caprun-throughsandsinteredltersareusedonplastictanks.
The fuel tank should be mounted securely.
Thefuelconnectionsmustbetightenedrmlysothattheaircannot
leak into the hose. Always check the cleanliness of the connection
surfaces before tightening. Air leaks in the fuel system will cause the
device to malfunction.
(accessory)
(accessory)
(accessory)
(accessory)
Volume length x height x width Order code
Wallas fuel tanks
D10451A
- 51 -
XC Duo
490541G
