Installation

Removing the plastic frame of the exhaust head

The 368202 plastic frame of the 4300exhaustheadisremovedbycarefullyby

pulling the plastic strips on both sides of the plastic frame outward while pulling the

plasticframeoutoftheexhausthead.

Fixing the hoses on the exhaust head

Fixthecombustiongasandintakeairhosesrmlyontheexhaustheadusingthe

hose clamps supplied with the accessory pack. Note the connection points of the

hosesontheexhausthead;theintakeairhoseisinstalledonthereducedhose

ttingonthe4300exhausthead,whilethecombustiongashoseisttedonØ28

mmhosetting.

The combustion gas hoses must be made of stainless steel.

Install the combustion gas ex-

hausthosetothishosetting

Install the combustion air intake

hosetothishosetting

Note the connection points of the hoses on the exhaust head; the

intakeairhoseisinstalledonthereducedhosettingonthe4300ex-

hausthead,whilethecombustiongashoseisttedonØ28mmhose

tting.

D10341D

- 58 -

XC Duo

490541G
