wallas xs duo User Manual

4310
min. 5°
4330
4330
4330
Installation
en
Side line of the vehicle
The 4300 exhaust head must be installed at a minimum downward incli-
nationofvedegrees(5°),ushwiththesidelineofthevehicle.
Fixing to the vehicle bottom
There are many possible ways to install the 4300exhaustheadtothevehicle’s
bottom structure. The 4310 basic chassis installation kit can be used to install the
combustion gas frame to most vehicles. The 4330extensionkitisavailablefor
special cases.
TYPICAL INSTALLATION:
SPECIAL SITUATION 1:
SPECIAL SITUATION 2:
SPECIAL SITUATION 3:
Vehicleoorstructure
D10341D
- 60 -
XC Duo
490541G
