wallas xs duo User Manual

min. 0,3 m
Installation
en
Combustion gas exhaust
Installing the exhaust head
Orientation of the exhaust head
The 4300exhaustheadmustbeinstalledsothatthecombustiongasesareex-
pelledtothesideofoneofthevehicle’sreartyres.Thecombustiongasisex-
haustedthroughthesmalleropeningintheplasticframeoftheexhausthead,and
seenfromtherearofthehead,thecombustiongasexhausthoseisxedonthe
unreduced(Ø28mm)hosetting.
The exhaust gases are removed from the smaller end of the grille in
the exhaust head 4300. The smaller end of the grille is located closest
to the rear wheel.
Combustion gas exhaust
D10341D
- 59 -
XC Duo
490541G
