wallas xs duo User Manual

XC Duo
4350
en
Technical information
Package contents
ScrewforironfastenerM6x12
FasteningscrewM6x30
Locking nut M6
Hose clamp 20 - 32 mm
Plastic holder, 15 mm
4 pcs
4 pcs
4 pcs
2 pcs
1 pcs
Stove XC Duo
Accessory bag 17735
Power cable with connector and integrated fuse 15 A (4m)
Steel fastener
1 pcs
1 pcs
2 pcs
1 pcs
Cover plug4 pcs
Installation, operation and maintenance instructions1 pcs
Control panel cable, 3 m
Control panel
Controlpanelfasteningscrews3,5x20mm(black)TX10
Control panel package 361070
Plasticcoverforexhausthead368202
1 pcs
1 pcs
Exhausthead
FasteningscrewM5x10
Exhausthead4300
Locking nut M5
Washer M5
1 pcs
1 pcs
4 pcs
2 pcs
2 pcs
1 pcs
4 pcs
1 pcs
Extensioncollar1 pcs
Controlpanelfasteningscrews3,5x40mm(black)TX104 pcs
L-shapeprole1 pcs
Hose clamp 20 - 32 mm2 pcs
Bracket set 43101 pcs
Mounting bracket2 pcs
Bracketprole2 pcs
Exhaustheadbracket2 pcs
FasteningscrewM5x108 pcs
Locking nut M58 pcs
Sheetmetalscrew4,8x138 pcs
Cover plate kit 43201 pcs
Cover plate2 pcs
Sheetmetalscrew4,8x134 pcs
Fasteningscrew3,9x161 pcs
Heat insulation Ø 30 mm, Fiber glass, 1,5 m 10301 pcs
ExhausttubeØ28mminox,2m10282 pcs
D80141A
- 42 -
XC Duo
490541G
