wallas xs duo User Manual

min. 300 mm
min. 300 mm
min. 400 mm
F
U
E
L
1030
4320
1028
Ø 43 mm
62 mm
Installation
en
Location under a window
Theexhausthead4300 shall not be installed under an opening window or closer
than300mmtothewindow’sedges.Iftheexhaustheadhastobeinstallednear
anopeningwindow,thewindowmustbepreventedfromopeningorttedwitha
switch that prevents the hob from being used when the window is open.
Installing the hoses
Installation
When you have chosen the location for the 4300exhausthead,youshouldndthe
best place to lead the combustion gas and intake air hoses through the bottom of
the vehicle.
DrilltwoholesofapproximatelyØ43mmforthehoses,asillustrated.Theholes
must be 62 mm apart. Install the 4320 bottom penetration cover plate set. Insulate
the combustion gas pipe with the 1030breglasssleeve.Iftheoorstructureof
the vehicle at the location of the combustion gas hose is not heat resistant, remove
part of the insulation and replace it with heat-resistant material.
Vehicleoorstructure
D10341D
- 57 -
XC Duo
490541G
