SPECIFICATIONS
54
English
SPECIFICATIONS
Item Specification
Model Name Cezanne 42
Panel
Active Area
(Diagonal, mm)
697.6845 x 392.256
Resolution 1920 x 1080
Brightness
(Nits, typ)
400 nits (min) to 500 nits (typical)
Contrast Ratio
(min)
3000:1
Response Time
(min)
6.5ms(g-g)
Aspect Ratio 1.77 (16:9)
Display color 16.7M
Audio/Video
Input/Output
Terminals
•HDMI x3
• AV with R/L Audio x2
• YPbPr with R/L Audio x1
• VGA with Audio mini jack blue x1
• SPDIF Out x1
• USB for service x1
• Tuner x1
• R/L Audio Line Out X1
Speaker Out 8W (2 channels)
AV Timing 480i/p, 720p, 1080i
PC Timing
640 x 480 @ 60Hz/75Hz, 800 x 600 @ 60Hz/75Hz,
1024 x 768 @ 60Hz/75Hz, 1280 x 720 @ 60Hz,1360
x 768 @ 60Hz, 1280 x 1024 @ 60Hz, 1366 x 768 @
60Hz
Power Consumption
(Watts)
163W
Power Consumption
(Standby, Watts)
<1W
