COMPONENTS
86037880 CHARIOT EXTRACTOR 01/16/07
3-4
1. Control Panel-Drive
2. Control Panel-Scrub
3. Control Housing
4. Pedal Platform
5. Rear Cover
6. Tank
7. Scrub Deck
8. Vacuum Shoes
9. Recovery Dome
10. Recovery Drain Hose
11. Solution Cover
12. Solution Drain Hose
1
2
3
4
5
6
7
8
9
10
11
12
