SCRUB DECK
86037880 CHARIOT EXTRACTOR 09/13/08
5-22
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86281150 39282 2 HOSE, 3/8 ID WIRE BOUND X 7”
2 86233150 20042 7 CLAMP, 3/8 HOSE (D-SLOT)
3 86281100 39274 1 HOSE, 1/2ID WIRE BOUND X 7”
4 86197760 78308 1 TEE, 1/4 STREET
5 86010730 87088 2 WASHER, 5/8 ID X 1.18 X .06 SS
6 86005580 56012 1 NIPPLE, 1/4 FPT QD
7 86197570 40028 1 HOSEBARB, 1/4MPT X 1/2 DL
8 86184900 790601 1 HOSEBARB, 1/4MPT X 1/2H 45 BR
9 86197590 40031 2 HOSEBARB, 1/8MPT X 3/8 90 D
10 86073620 67017 1 BRKT, JET MOUNT
11 86270830 57023 3 NUT, 5/16-18 HEX NYLOCK SS
12 86274290 70162 2 SCR, 10-32 X 3/8 PPHMS SS
13 86010640 87016 2 WASHER, #10 LOCK EXT STAR SS
14 86004570 44067 2 JET BODY, MINI PROMAX BODY
15 86241730 44107 2 JET MINI PROMAX 9506
16 86271870 57290 2 NUT, 1/4-20 HEX NYLOCK THIN SS
17 86010630 87013 4 WASHER, 1/4 ID X 5/8 OD SS
18 86255950 73869 1 STOP, MOUNT
19 86092840 41535 1 HOPPER, CYL. SCRUB DECK 24
20 86258870 84168 1 VALVE, 120V 110 PSI SOLENOID
21 86197550 40014 2 HOSEBARB, 1/4MPT X 3/8 DL
22 86197730 78024 1 TEE, 1/4 BRANCH
23 86006530 70057 2 SCR, 1/4-20 X 1 PPHMS SS
24 86277150 70797 2 SCR, 5/16-18 X 2 BSHCS SS
25 86242120 48090 2 KNOB, 1.0 OD X 5/16-18
26 86260400 880212 1 WIRE ASM, REV POLARITY JUMPER
27 86002830 27196 2 CABLE TIE, .375 X 24.7
28 86217740 53815 2 DRIVE MOTOR (2 UNITS/CARTON)
29 - OPEN - -
30 86078060 149997 4 PAD, SKID BAR, LARGE
31 86277530 70861 8 SCR, M8 X 1.25 X 20LG BSHCS SS
32 86086100 66859 1 RETAINER, DEFLECTOR
33 86006560 70083 3 SCR, 5/16-18 X 1 HHCS SS
34 86010670 87029 15 WASHER, 5/16 FLAT SS
35 86230500 02498 2 BRUSH, 24” CYL, C-NYLON
36 86064010 29270 1 DEFLECTOR, MACHINED
37 86277530 70861 12 SCR, M8X1.25 X 20 LG BSHCS SS
38 86279130 87083 12 WASHER, 5/16 SPLIT LOCK PLTD
39 86270990 57090 4 NUT, 10-32 HEX NYLOCK SS
40 86010650 87018 4 WASHER, #10 X 9/16 OD
41 86197630 40042 1 HOSEBARB, 1/4MPT X 1/2H 90D DL
42 86264940 27051 3 CABLE TIE, 11.38” UL/CSA
43 86092540 34453 1 FRAME, EXTRACTOR DECK 24IN
