Windsor chariot iExtract CE24 User Manual

SUGGESTED SPARE PARTS
86037880 CHARIOT EXTRACTOR 01/16/07
5-63
PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM NOTES:
86001910 14606 BREAKER, 30A 50VDC CIRCUIT
86002000 14717 BREAKER, 3 AMP
86251410 67506 RELAY, 15A 36V MINI
86007140 72130 SWITCH, SPST 2-POSITION ROCKER
86007190 72161 SWITCH KEY DPST
86007240 72190 SWITCH, SEALED PB ROUND
86001740 140816 BRAKE, 36 VDC W/CONNECTOR
86002730 270085 CHAIN, ISO 08B 12.7 MM PITCH
86001730 140804 BREAKER, 18A 250VDC, 50VDC
86007130 72128 SWITCH, DPDT 2-POSITION ROCKER
86006370 67315 RELAY, 36VDC 100AMP HVY DUTY
86028890 84098 VALVE, 115V CMD SOLENOID SVC
86252980 730369 SCREEN, 100 MESH
86241730 44107 JET, MINI PROMAX 9506
