Machine description | 3 | English
Operating instructions PT Series | 89014547; 2021-03 | 15
3.7 Suction tube with level control (optional)
A suction tube is needed to suck out the chemicals from the canisters.
– Do not place the suction tube for the rinse aid in the canister with detergent or vice versa.
– Only use the suction tube with sufficiently stable canisters. Narrow and tall canisters can tip as soon as the suction
tube is pulled.
– Do not pull on the dosing hose or main power cable, as this may lead to a defect.
Colour
(cap)
Canister
Blue Rinse aid
Grey Detergent
Item Name
1 Float switch for level control
The float switch (1) can detect a defect in the chemicals and indicates this on the display. }43
See also
2 Pictograms [}43]
