INSTALLATION NOTES:
Ensure all the seals are in good condition
and seated properly.
To ease assembly of flue components,
grease seals lightly with the solvent free
grease supplied.
A terminal guard must be fitted if the
terminal is 2m or less above a surface where
people have access.
Refer to separate flue installation manual
supplied with the flue kits available for this
boiler.
NOTE: All horizontal flue sections must rise by
52mm for each metre away from the
boiler to ensure that the condensate
flows back to the boiler for safe
disposal via the condensate waste
pipe.
FLUE INSTALLATION
FLUE INSTALLATION
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR HEATSLAVE EXTERNAL 12/18-18/25-25/32
8 716 113 389d (03/2010)
22
INSTALLATION
Balanced external oilfit flue kits and components 80/125mm Ø
(not supplied):
External horizontal flue kit 7 716 190 084
In-line elbow 90° x 1 7 716 190 034
Stainless steel terminal guard 7 716 190 050
80/125mmØ High level horizontal external flue kit 7 716 190 057
80/125mmØ Vertical External flue kit 7 716 190 053
80/125mmØ Balanced external flue 1m extension kit 7 716 190 054
80/125mmØ Balanced external flue 90° swept elbow kit 7 716 190 055
80/125mmØ Balanced external flue 45° elbow (2 off) kit 7 716 190 056
