Xerox B1025 System Administrator Guide

LDAP Server
Lightweight Directory Access Protocol (LDAP) is a protocol used to process queries and updates to an
LDAP information directory, on an external server. LDAP can also be used for network authentication
and authorization.
The LDAP Server page displays the current LDAP servers configured for your printer. You can configure
a maximum of nine LDAP servers for your printer.
Note: Before you configure an LDAP server, ensure that Network Authentication is enabled. For
details, refer to Setting the Login Method.
AAddddiinngg oorr EEddiittiinngg aann LLDDAAPP SSeerrvveerr
1. In Xerox
®
CentreWare
®
Internet Services, click Properties→Connectivity→Protocols.
2. Click LDAP Directory.
3. To edit the default LDAP server settings, for LDAP (Default), click Edit.
4. To configure another LDAP server, for Additional LDAP Servers, click Add or Edit.
5. To configure server information, perform the following steps.
a. Type a Friendly Name. The Friendly Name appears as the default description for the server
when a user scans a job at the control panel.
b. Select the Name or IP Address type. Fields update based on the options that you select.
c. Type the LDAP IP address or host name and port number.
d. Type the appropriately formatted address or host name of your backup server, then change
the default port number as needed.
6. To configure LDAP Access, perform the following steps.
a. Enter the Search Directory Root.
Note:
• It is not necessary to include DC=Users in the Search Directory Root.
• For details on Base DN formatting, refer to the RFC 2849 - LDAP Data Interchange
Format (LDIF) Technical Specification on the IETF website.
b. For Login Credentials to Access LDAP Server, select an option.
• System: This setting instructs the printer to use specific credentials when the printer
accesses the server.
• Authenticated User: The printer uses the user name and password of the authenticated
user to access the server.
c. To look up the user DN, for Lookup User's DN, select Enable.
7. To configure LDAP Bind, perform the following steps.
30
Xerox
®
B1025 Multifunction Printer
System Administrator Guide
Network Connectivity

Xerox B1025 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Booklet printing function	Yes
Print speed (black, normal quality, A4/US Letter)	25 ppm
Duplex print speed (black, normal quality, A4/US Letter)	13 ppm
PCL fonts	107
Printer fonts	PCL, PostScript
Digital sender	-
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 50000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 6, PostScript
Compatible memory cards	MicroSD (TransFlash)
Maximum internal memory	1536 MB
Sound pressure level (quiet mode)	30 dB
Wi-Fi	No
Security features	Firmware Verification, Security Certificate Management, Signed Certificate Creation, Audit Log
Cabling technology	10/100Base-T(X)
Security algorithms	AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	110 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (off)	2 W
Power consumption (sleep)	1.5 W
Power consumption (average operating)	650 W
Energy Star Typical Electricity Consumption (TEC)	1.65 kWh/week
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	750 mm
Package width	771 mm
Package height	600 mm
Package weight	32300 g
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Scan speed (color)	30 ppm
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Optical scanning resolution	600 x 600 DPI
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Other operating systems supported	Solaris 11
Mobile operating systems supported	Android
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Copier resize	25 - 400 %
Time to first copy (black, normal)	7.6 s
Copy speed (black, normal quality, A4)	25 cpm
Modem speed	33.6 Kbit/s
Total input capacity	100 sheets
Total output capacity	250 sheets
Product color	Black, White
Market positioning	Business
Paper tray media types	Bond paper, Heavy paper, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper, Thin paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3

Weight and Dimensions

Depth	555.3 mm
Width	560 mm
Height	417 mm
