Xerox Phaser 3155 Service Manual

10-20 Phaser 3140/3155/3160 Printer Service Manual
Wiring
3155 Laser Unit Wiring
Controller Board
Power Supply
Board
FUSER_THERM1
THERMISTOR1
LIVE
LIVE
FAN_POWER
Fan
GND
N.C.
NEUTRAL
1
2
1
2
Fuser
Laser
Interlock
+24VDC
+5VDC
CN4
CN12 CON1
CON3
INLET1
CN1
CN5
1
3
4
5
2
24V
GND
nPMOTOR
nLREADY
LSU_CLK
nLD_ENABLE
DAC_OUT
GND
nHSYNC
nLSU_SH
6
8
9
10
7
6
8
9
10
7
1
3
4
5
2
GND
DO1-
DO1+
GND
5V_LSU
11
13
14
15
12
1
3
4
5
2
s3160-151
NEUTRAL
1
2
3
3155
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3155 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	12000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 105 g/m²
Custom media sizes	76 x 127 mm - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003 Server/2008 Server, Vista, Mac OSX 10.3-10.6, Linux OS
Sustainability certificates	ENERGY STAR
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
