2-14 Phaser 3140/3155/3160 Printer Service Manual
Theory of Operation
Supply
• Output voltage: -400 V ~ -800 VDC ± 50 V (ZENER using, DEV)
• Input contrast of the output stability degree: under ± 5%
Loading contrast: ± 5% or less
• Output voltage rising time: 50 ms Max
• Output voltage falling time: 50 ms Max
• Output Loading range: 10 M Ohm ~ 1000 M Ohm
• Output control signal (BIAS-PWM): The CPU is HV output when PWM is Low.
Power Supply
The Power Supply (switch-mode power supply, SMPS) supplies DC power for driving
the printer, and the AC heater control, which supplies power to the Fuser.
The Power Supply has two output channels: +5.0 V and +24 V.
AC Input
• Input rated voltage:
• AC 110 V~127 V
• AC 220 V~240 V
• Input voltage fluctuation range:
• AC 99 V~140 V
• AC 198 V~265 V
• Rated frequency: 50/60 Hz
• Rated frequency fluctuating range: 47~63 Hz
• Input current: under 4.0 A/2.0 A (when the lamp is Off or rated voltage is
inputted/outputted)
Rated Output Power
Item CH1 CH2 Remark
Channel Name +5.0 V +24.0 V
Connector Pin CON2
5V PIN: 8, 15, 16
CON2
24 V PIN: 5, 6, 9, 10,
12
Rated Output +5.1 V ± 5%
(4.845 ~ 5.355 V)
+24 V ± 15%
(20.4 ~ 27.6 V)
Max. Output Current 1.2 A 2.0 A
Peak Loading Current 1.5 A 2.5 A Under
100 ms
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3155 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	12000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 105 g/m²
Custom media sizes	76 x 127 mm - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003 Server/2008 Server, Vista, Mac OSX 10.3-10.6, Linux OS
Sustainability certificates	ENERGY STAR
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
