Phaser 3140/3155/3160 Printer Service Manual 3-11
Error Messages and Codes
Paper Jam 2
A Jam 2 occurs when there is a jam in front of or inside of the Fuser, or when the
media is stuck in the Exit Roller and in the Fuser just after passing through the
Feed Actuator.
If the media is rolled in the Fuser Roller, it can be caused by:
• A Fuser guide claw is broken or bent.
• The spring of a guide claw is broken or bent.
• The Heat Roller or Pressure Roller is seriously contaminated with toner.
Initial Actions
• Check the paper path for obstructions or debris.
• Cycle printer power.
• If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Power Supply Board, PL1.0.1
■ Feed Actuator, PL6.0.57
■ Map 4 - 110V and 220V Power Supply
Boards
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Is the jam occurring in front of or
inside of the Fuser?
Replace the
Power Supply
(page 8-54).
If the problem
persists go to
step 2.
Go to step 2.
2 Is the jam occurring in the exit roller
and the Fuser just after passing
through the Feed Actuator?
Replace the
Feed Actuator
(page 8-40).
Complete.
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3155 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	12000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 105 g/m²
Custom media sizes	76 x 127 mm - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003 Server/2008 Server, Vista, Mac OSX 10.3-10.6, Linux OS
Sustainability certificates	ENERGY STAR
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
