Xerox Phaser 3155 Service Manual

3-8 Phaser 3140/3155/3160 Printer Service Manual
Error Messages and Codes
2. Gently pull the paper out of the output tray.
Note
If you do not see the jammed paper, or if there is any resistance when you
pull, stop and go to the next step.
3. Open the Rear Cover.
4. Pull the Fuser pressure levers down and remove the paper.
5. Return the pressure levers to their original position.
6. Close the Rear Cover.
7. Open and close the Front Cover, printing automatically resumes.
Paper Jam 0
The leading edge of the paper is jammed between the Pick Up Roller and the
Paper Feed Sensor.
s3160-095
s3160-069
Paper Feed Sensor
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3155 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	12000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 105 g/m²
Custom media sizes	76 x 127 mm - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003 Server/2008 Server, Vista, Mac OSX 10.3-10.6, Linux OS
Sustainability certificates	ENERGY STAR
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
