Xerox Phaser 3155 Service Manual

Phaser 3140/3155/3160 Printer Service Manual 4-13
General Troubleshooting
No Power
When the printer is turned On, no activity is detected.
Warning
Hazardous voltage is connected to the Power Supply.
Initial Actions
• Cycle printer power.
• If problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Power Cord, PL1.0.13
■ Power Supply, PL1.0.1
■ Controller Board, PL1.0.2
■ Map 1 - Controller Board (3140)
■ Map 2 - Controller Board (3155)
■ Map 3 - Controller Board (3160B/
3160N)
■ 3140 Power Supply Wiring
■ 3155 Power Supply Wiring
■ 3160 Power Supply Wiring
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the connection to the wall outlet.
Is the printer connected to the outlet?
Go to step 2. Connect to
the wall
outlet.
2 Check the condition of the Power Cord.
Is the Power Cord damaged?
Replace the
Power Cord.
Go to step 3.
3 Check the wall outlet.
Is the proper supply voltage present?
Go to step 4. Use a
different
outlet.
4 Check the output supplies on the Power
Supply.
Check for +24 V at each of the following
pins: CON2-5, 6, 9, 10, and 12.
Check for +5 V at CON2-8, 15, and 16.
Is the correct voltage present at each
pin?
Go to step 5. Replace the
Power
Supply
(page 8-54).
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3155 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	12000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 105 g/m²
Custom media sizes	76 x 127 mm - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003 Server/2008 Server, Vista, Mac OSX 10.3-10.6, Linux OS
Sustainability certificates	ENERGY STAR
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
