Xerox Phaser 3250 User Guide

Installing Printer Software in Windows
9
7 You can also change the printer name, set the printer to be
shared on the network, set the printer as the default printer, and
change the port name of each printer. Click Next.
To install this software on a server, select the Setting up this
printer on a server checkbox.
8 After the installation is finished, a window asking you to print a
test page appears. If you choose to print a test page, select the
checkbox and click
Next.
Otherwise, just click
Next and skip to step 10.
9 If the test page prints out correctly, click Yes.
If not, click No to reprint it.
10 Click Finish.
NOTE: After setup is complete, if your printer driver does not work
properly, reinstall the printer driver. See “Reinstalling Printer
Software” on page 9.
Reinstalling Printer Software
You can reinstall the software if installation fails.
1 Start Windows.
2 From the Start menu select Programs or All Programs →
your printer driver name → Maintenance.
3 Select Repair and click Next.
4 The list of printers available on the network appears. Select the
printer you want to install from the list and then click Next.
• If you do not see your printer on the list, click Update to
refresh the list, or select Add TCP/IP Port to add your printer
to the network. To add the printer to the network, enter the
port name and the IP address for the printer.
• To find a shared network printer (UNC Path), select Shared
Printer [UNC] and enter the shared name manually or find a
shared printer by clicking the Browse button.
You will see a component list so that you can reinstall any item
individually.
NOTE: If your printer is not already connected to the computer, the
following window will appear.
• After connecting the printer, click Next.
• If you don’t want to connect the printer at this time, click Next, and
No on the following screen. Then the installation will start and a
test page will not be printed at the end of the installation.
• The reinstallation window that appears in this User Guide may
differ depending on the printer and interface in use.

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
