Xerox Phaser 3250 User Guide

Basic Printing
18
Troubleshooting Tab
Use the Troubleshooting tab for printer information page. See
“Printing a Document” on page 13 for more information about accessing
printer properties.
Click the
Troubleshooting tab to display the properties shown below.
Printer Information Pages
To print information pages or to perform diagnostic actions, select
an item from the list below and click Print.
Web Links
If you have an Internet connection and a browser installed, click one
of the web links to connect to a web page directly from the driver.
About
Use the About tab to display the copyright notice and the version
number of the driver.
Printer Tab
If you access printer properties through the Printers folder, you can view
the
Printer tab. You can set the printer configuration.
The following procedure is for Windows XP. For other Windows OS, refer
to the corresponding Windows User's Guide or online help.
1 Click the Windows Start menu.
2 Select Printers and Faxes.
3 Select your printer driver icon.
4 Right-click on the printer driver icon and select Properties.
5 Click the Printer tab and set the options.
Using a Favorite Setting
The Favorites option, which is visible on each properties tab, allows you
to save the current properties settings for future use.
To save a
Favorites item:
1 Change the settings as needed on each tab.
2 Enter a name for the item in the Favorites input box.
3 Click Save.
When you save Favorites, all current driver settings are saved.
To use a saved setting, select the item from the Favorites drop down
list. The printer is now set to print according to the Favorites setting you
selected.
To delete a Favorites item, select it from the list and click
Delete .
You can also restore the printer driver’s default settings by selecting
Printer Default from the list.
Using Help
Your printer has a help screen that can be activated by clicking the Help
button in the printer properties window. These help screens give detailed
information about the printer features provided by the printer driver.
You can also click from the upper right corner of the window, and
then click on any setting.

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
