Xerox Phaser 3250 User Guide

Using Your Printer in Linux
29
Using the MFP Configurator
MFP Configurator is a tool primarily intended for configuring Printer.
After installing the MFP Driver, the MFP Configurator icon will
automatically be created on your desktop.
Opening the MFP Configurator
1 Double-click MFP Configurator on the desktop.
You can also click the Startup Menu icon and select Xerox MFP
and then MFP Configurator.
2 Press each button on the Modules pane to switch to the
corresponding configuration window.
You can use the onscreen help by clicking Help.
3 After changing the configurations, click Exit to close the MFP
Configurator.
Printers Configuration button
Ports Configuration button
Printers Configuration
Printers configuration has the two tabs: Printers and Classes .
Printers Tab
You can see the current system’s printer configuration by clicking on the
printer icon button on the left side of the MFP Configurator window.
You can use the following printer control buttons:
• Refresh: renews the available printers list.
• Add Printer: allows you to add a new printer.
• Remove Printer: removes the selected printer.
• Set as Default: sets the current printer as a default printer.
• Stop/Start: stops/starts the printer.
• Test: allows you to print a test page to check if the machine is
working properly.
• Properties: allows you to view and change the printer properties.
For details, see page 30.
Shows all of the
installed printer.
Switches to Printer
configuration.
Shows the status,
model name and URI of
your printer.

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
