Xerox VersaLink C605 User Manual

• For Windows, Booklet Layout is on the Page Layout tab. Page Layout is on the Document Options
tab.
• For Macintosh, in the Print window, in Xerox Features, Booklet Layout is on the Paper/Output list.
When you print booklets using the Windows PostScript or Macintosh driver, you can specify the gutter
and creep.
• Gutter: Specifies the horizontal distance in points between the page images. A point is 0.35 mm
(1/72 in.).
• Creep: Specifies how much the page images shift outward in tenths of a point. Shifting
compensates for the thickness of the folded paper, which can cause the page images to shift
outward slightly when folded. You can select a value from zero to 1 point.
Gutter
Creep
SSeelleeccttiinngg FFiinniisshheerr OOppttiioonnss
With the optional finisher option installed on the printer, you can request stapled documents right
from your desktop computer. The stapler can staple up to 30 sheets of 105 g/m
2
.
1. From the Printing Options tab, locate the Finishing option, then select 1 Staple.
2. Click OK.
The stapled prints are delivered to the finisher unit.
SSeelleeccttiinngg MMaaiillbbooxx OOppttiioonnss
With the optional mailbox option installed on the printer, you can send prints to a specific mailbox
bin right from your desktop computer.
1. From the Printing Options tab, locate the Output Destination option, then select one of the
mailbox bins.
2. Click OK.
The prints are delivered to the selected mailbox bin.
UUssiinngg SSppeecciiaall PPaaggeess
The Special Pages options control how covers, inserts, and exception pages are added to your printed
document.
Xerox
®
VersaLink
®
C605 Color Multifunction Printer
User Guide
139
Printing

Xerox VersaLink C605 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Booklet printing function	Yes
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	53 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 400 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5 s
Time to first copy (color, normal)	7 s
Duplex copy speed (black, US Letter)	47 ppm
Copy speed (black, normal quality, A4)	53 cpm
Scan to	E-mail, File, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Maximum scan area	216 x 356 mm
Output color depth	8 bit
Scan speed (color)	46 ppm
Image formats supported	JPG, TIF
Duplex scan speed (black)	71 ppm
Duplex scan speed (color)	52 ppm
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	2000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	120000 pages per month
Recommended duty cycle	0 - 15000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Internal memory	4096 MB
Card reader integrated	No
Internal storage capacity	250 GB
Sound power level (standby)	33.5 dB
Sound pressure level (printing)	54.7 dB
Wi-Fi standards	Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD, LDAP, FTP
Standard interfaces	USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.9 W
Power consumption (standby)	90 W
Power consumption (printing)	820 W
Power consumption (average operating)	- W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	15 - 85 °C
Operating relative humidity (H-H)	10 - 32 %
Package depth	655 mm
Package width	594 mm
Package height	789 mm
Package weight	44000 g
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	400 sheets
Maximum input capacity	3250 sheets
Auto document feeder (ADF) input capacity	100 sheets
Custom media width	76 - 190 mm
Custom media length	216 - 356 mm
Duplex media weight	60 - 128 g/m²
Paper tray media types	Card stock, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead
Maximum ISO A-series paper size	A4
Sustainability certificates	ENERGY STAR
Market positioning	Business

Weight and Dimensions

Depth	503 mm
Width	470 mm
Height	643.7 mm
