Page #199 background imageLoading...
Page #199 background image
Caution: Use of non-Xerox supplies is not recommended. The Xerox Warranty, Service
Agreement, and Total Satisfaction Guarantee do not cover damage, malfunction, or
degradation of performance caused by use of non-Xerox supplies, or the use of Xerox supplies
not specified for this printer. The Total Satisfaction Guarantee is available in the United States
and Canada. Coverage could vary outside these areas. Please contact your Xerox representative
for details.
SSuuppppllyy SSttaattuuss IInnffoorrmmaattiioonn
You can check the supplies status, customize the alerts that appear on the control panel, and
configure email alert notifications. For more information, refer to the Supply Status.
SSuupppplliieess UUssaaggee RReeppoorrtt
The Supplies Usage Report provides coverage information and part numbers for reordering supplies.
The date a supply item was installed appears on the report.
To print the Supplies Usage Report:
1. At the printer control panel, press the Home button.
2. Touch DeviceAboutInformation Pages.
3. Touch Supplies Usage Report.
4. To return to the Home screen, press the Home button.
TToonneerr CCaarrttrriiddggeess
GGeenneerraall PPrreeccaauuttiioonnss
WARNING:
When replacing a toner cartridge, be careful not to spill the toner. If any toner spills, avoid
contact with clothes, skin, eyes, and mouth. Do not inhale the toner dust.
Keep toner cartridges out of the reach of children. If a child accidentally swallows toner,
have the child spit out the toner, and rinse the mouth with water. Consult a physician
immediately.
Use a damp cloth to wipe off spilled toner. Never use a vacuum cleaner to remove spills.
Electric sparks inside the vacuum cleaner can cause a fire or explosion. If you spill a large
volume of toner, contact your local Xerox representative.
Never throw a toner cartridge into an open flame. Remaining toner in the cartridge can
catch fire and cause burn injuries or an explosion.
RReeppllaacciinngg aa TToonneerr CCaarrttrriiddggee
A message appears on the control panel when a toner cartridge must be replaced.
Note: Each toner cartridge includes installation instructions.
Xerox
®
VersaLink
®
C605 Color Multifunction Printer
User Guide
199
Maintenance

Table of Contents

Other manuals for Xerox VersaLink C605

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink C605 and is the answer not in the manual?

Xerox VersaLink C605 Specifications

General IconGeneral
Print technologyLaser
Maximum resolution1200 x 2400 DPI
Booklet printing functionYes
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)53 ppm
Print speed (color, normal quality, A4/US Letter)50 ppm
Copier resize25 - 400 %
Maximum copy resolution600 x 400 DPI
Maximum number of copies999 copies
Time to first copy (black, normal)5 s
Time to first copy (color, normal)7 s
Duplex copy speed (black, US Letter)47 ppm
Copy speed (black, normal quality, A4)53 cpm
Scan toE-mail, File, USB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Input color depth24 bit
Maximum scan area216 x 356 mm
Output color depth8 bit
Scan speed (color)46 ppm
Image formats supportedJPG, TIF
Duplex scan speed (black)71 ppm
Duplex scan speed (color)52 ppm
Document formats supportedPDF, XPS
Optical scanning resolution600 x 600 DPI
FaxingMono faxing
Fax memory4 MB
Modem speed33.6 Kbit/s
Fax forwarding toE-mail
Fax coding methodsJBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)2000
Digital sender-
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle120000 pages per month
Recommended duty cycle0 - 15000 pages per month
Page description languagesHP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Internal memory4096 MB
Card reader integratedNo
Internal storage capacity250 GB
Sound power level (standby)33.5 dB
Sound pressure level (printing)54.7 dB
Wi-Fi standardsWi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print
Supported network protocols (IPv4)TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD, LDAP, FTP
Standard interfacesUSB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity1
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (sleep)0.9 W
Power consumption (standby)90 W
Power consumption (printing)820 W
Power consumption (average operating)- W
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)15 - 85 °C
Operating relative humidity (H-H)10 - 32 %
Package depth655 mm
Package width594 mm
Package height789 mm
Package weight44000 g
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Paper input typePaper tray
Total input capacity550 sheets
Total output capacity400 sheets
Maximum input capacity3250 sheets
Auto document feeder (ADF) input capacity100 sheets
Custom media width76 - 190 mm
Custom media length216 - 356 mm
Duplex media weight60 - 128 g/m²
Paper tray media typesCard stock, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight60 - 220 g/m²
Multi-purpose tray media typesBond paper, Envelopes, Labels, Letterhead
Maximum ISO A-series paper sizeA4
Sustainability certificatesENERGY STAR
Market positioningBusiness
Weight and Dimensions IconWeight and Dimensions
Depth503 mm
Width470 mm
Height643.7 mm
