Xerox VersaLink C605 User Manual

Note:
• Not all applications support AirPrint
®
.
• Wireless devices must join the same wireless network as the printer.
• For AirPrint
®
to function, both IPP and Bonjour
®
(mDNS) protocols must be enabled.
• The device that submits the AirPrint
®
job must be on the same subnet as the printer. To
allow devices to print from different subnets, configure your network to pass multicast DNS
traffic across subnets.
• The Mac OS device must be Mac OS 10.7 or later.
• AirPrint
®
-enabled printers work with all models of iPad, iPhone (3GS or later), and iPod
touch (3rd generation or later), running the latest version of iOS.
1. At your computer, open a Web browser. In the address field, type the IP address of the printer,
then press Enter or Return.
Note: If you do not know the IP address for your printer, refer to Finding the IP
Address of Your Printer.
2. In the Embedded Web Server, click Home→Connectivity.
Note: If this feature does not appear, log in as a system administrator.
3. For Mobile Printing, click AirPrint
®
.
4. To enable AirPrint
®
, click the Enable toggle button.
Note: AirPrint
®
is enabled by default when IPP and Bonjour
®
(mDNS) are both
enabled.
• To change the printer name, in the Name field, enter a new name.
• To enter a location for the printer, in the Location field, enter the location of the printer.
• To enter a physical location or address for the printer, in the Geo-Location field, enter the
geographic latitude and longitude coordinates in decimal form. For example, use coordinates
such as 45.325026, -122.766831 for a location.
5. Click OK.
6. To activate your changes, at the prompt, click Restart Now.
CCoonnffiigguurriinngg GGooooggllee CClloouudd PPrriinntt
Google Cloud Print allows you to print documents that are stored in the cloud without using a print
driver.
Before you begin:
• Set up a Google email account.
• Configure the printer to use IPv4.
• Configure Proxy Server settings as needed.
50
Xerox
®
VersaLink
®
C605 Color Multifunction Printer
User Guide
Getting Started

Xerox VersaLink C605 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Booklet printing function	Yes
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	53 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 400 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5 s
Time to first copy (color, normal)	7 s
Duplex copy speed (black, US Letter)	47 ppm
Copy speed (black, normal quality, A4)	53 cpm
Scan to	E-mail, File, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Maximum scan area	216 x 356 mm
Output color depth	8 bit
Scan speed (color)	46 ppm
Image formats supported	JPG, TIF
Duplex scan speed (black)	71 ppm
Duplex scan speed (color)	52 ppm
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	2000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	120000 pages per month
Recommended duty cycle	0 - 15000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Internal memory	4096 MB
Card reader integrated	No
Internal storage capacity	250 GB
Sound power level (standby)	33.5 dB
Sound pressure level (printing)	54.7 dB
Wi-Fi standards	Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD, LDAP, FTP
Standard interfaces	USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.9 W
Power consumption (standby)	90 W
Power consumption (printing)	820 W
Power consumption (average operating)	- W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	15 - 85 °C
Operating relative humidity (H-H)	10 - 32 %
Package depth	655 mm
Package width	594 mm
Package height	789 mm
Package weight	44000 g
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	400 sheets
Maximum input capacity	3250 sheets
Auto document feeder (ADF) input capacity	100 sheets
Custom media width	76 - 190 mm
Custom media length	216 - 356 mm
Duplex media weight	60 - 128 g/m²
Paper tray media types	Card stock, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead
Maximum ISO A-series paper size	A4
Sustainability certificates	ENERGY STAR
Market positioning	Business

Weight and Dimensions

Depth	503 mm
Width	470 mm
Height	643.7 mm
