Xerox VersaLink C605 User Manual

AAddddiinngg aa FFrroonntt CCoovveerr
You can print the first page of your copy job on different paper, such as colored or heavyweight
paper. The printer selects the special paper from a different tray. The cover can be blank or printed.
Note: This function is available only on printers with an optional Productivity Kit installed only.
To add a front cover to your copy job:
1. At the printer control panel, press the Home button.
2. Touch Copy.
3. Touch Front Cover.
4. Touch the Front Cover toggle button.
Note: If Paper Supply is set to Auto Select, a notification appears confirming that the
Paper Supply has been changed to Tray 1.
5. Touch Printing Options, then select an option.
• Blank: This option inserts a blank front cover.
• Print on Side 1 Only: This option prints on the front side of the cover only.
• Print on Side 2 Only: This option prints on the back side of the cover only.
• Print on Both Sides: This option prints on both sides of the cover.
6. Touch Paper Supply, then select the required paper source.
7. Touch OK.
EErraassiinngg tthhee EEddggeess ooff CCooppiieess
You can erase content from the edges of your copies using the Edge Erase feature. You can specify
the amount to erase on the right, left, top, and bottom edges.
To erase the edges of copies:
1. At the printer control panel, press the Home button.
2. Touch Copy.
3. Touch Edge Erase.
4. Select one of the following options.
• All Edges: This option erases all four edges by the same amount. To adjust the amount to
erase, move the slider.
• Print to Edge: This option prints with no edge erase.
• Individual Edges: This option allows you to specify different amounts to erase from the edges.
Select an erase option.
– Mirror Edges: This option allows you to set the Edge Erase for Side 1, and matches the
Side 2 Edge Erase accordingly. To adjust the edge erase, move the slider.
– Independent Edges: This option allows you to set the Edge Erase on Side 1 and Side 2
independently of each other. Touch the appropriate field. To adjust the Edge Erase, move
the slider.
96
Xerox
®
VersaLink
®
C605 Color Multifunction Printer
User Guide
Xerox
®
Apps

Xerox VersaLink C605 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Booklet printing function	Yes
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	53 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 400 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	5 s
Time to first copy (color, normal)	7 s
Duplex copy speed (black, US Letter)	47 ppm
Copy speed (black, normal quality, A4)	53 cpm
Scan to	E-mail, File, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Maximum scan area	216 x 356 mm
Output color depth	8 bit
Scan speed (color)	46 ppm
Image formats supported	JPG, TIF
Duplex scan speed (black)	71 ppm
Duplex scan speed (color)	52 ppm
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	Mono faxing
Fax memory	4 MB
Modem speed	33.6 Kbit/s
Fax forwarding to	E-mail
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	2000
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	120000 pages per month
Recommended duty cycle	0 - 15000 pages per month
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Internal memory	4096 MB
Card reader integrated	No
Internal storage capacity	250 GB
Sound power level (standby)	33.5 dB
Sound pressure level (printing)	54.7 dB
Wi-Fi standards	Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD, LDAP, FTP
Standard interfaces	USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1), Wireless LAN
USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.9 W
Power consumption (standby)	90 W
Power consumption (printing)	820 W
Power consumption (average operating)	- W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	15 - 85 °C
Operating relative humidity (H-H)	10 - 32 %
Package depth	655 mm
Package width	594 mm
Package height	789 mm
Package weight	44000 g
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	400 sheets
Maximum input capacity	3250 sheets
Auto document feeder (ADF) input capacity	100 sheets
Custom media width	76 - 190 mm
Custom media length	216 - 356 mm
Duplex media weight	60 - 128 g/m²
Paper tray media types	Card stock, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead
Maximum ISO A-series paper size	A4
Sustainability certificates	ENERGY STAR
Market positioning	Business

Weight and Dimensions

Depth	503 mm
Width	470 mm
Height	643.7 mm
