Your WorkCentre
Inside the WorkCentre
There are 2 Customer Replaceable Units in
the WorkCentre, the SMart Kit Drum
Cartridge (7) and the Toner Cartridge (8).
If the Finisher option is installed there is also
a replacement Staple Cartridge.
The Serial Number (9) is also located here.
If the machine display is on, the Serial
Number can also be seen by pressing the
Machine Status button.
1
4
2
3
Control Panel:
Touch Screen and
Numeric Keypad.
Finisher:
Optional Finisher
collates and staples
output.
Paper Trays:
Tray 1 is standard, Trays
2, 3 and 4 are optional.
All the trays are
functionally the same.
Trays 2, 3 and 4 are
interchangeable.
Document Feeder:
Used for scanning multiple
documents. The
Document Glass
underneath is used for
scanning single
documents, bound
documents etc.
Bypass Tray:
Used for non-standard
printing media.
5
1
4
3
2
1
2
3
4
5
6
6
Stand:
Note that a cabinet is
available when trays 3 and
4 are not installed.
9
8
7

Xerox WorkCentre 4150 Specifications

General

Brand	Xerox
Model	WorkCentre 4150
Category	All in One Printer
Language	English
